Role Based Security

Overview

Role based security (Access Protection) is applied based on the user login credentials to determine chart and feature access within org.manager. It is possible to have different levels of access depending on the employee record associated to users.

In org.manager, access can be configured at different levels:

  • Attributes - employee id, salary, position title

  • Perspectives - basic chart, org tree with budget analysis, dashboard

  • Features - data exports, PDF exports, search

  • Hierarchical - structural access



How it works

org.manager utilises information from two sources to determine the level of access a user should be granted.

  1. The user identifier detected at login

  2. The HR data used to build the organisational charts

org.manager maps the Unique User Identifier (Name ID) passed during Single Sign On with an Employee Record in the HR data.

Having the Unique User Identifier as part of the person data attributes imported into org.manager is essential for the application to determine what record in the data is associated with the user who has logged in.

After the authentication process completes and the employee record linked to the user is established, the application then proceeds to work out what level of access they should be granted using the list of security rules.

Security rules are pre-configured conditional logic using the HR data imported into org.manager. The conditions can be directly related to the user’s employee record, or to an object linked to it (e.g. position, org unit, job, etc).

Depending on which conditions are met by their employee record, users can be granted more or less access.

Management Access

For instance, a user in a management role might be required to have access to additional perspectives besides the basic organisational chart, remuneration and budgeting attributes, a more comprehensive set of perspectives including dashboards and sunburst diagrams, and additional options to allow them to run data exports or create simulations for organisational modelling.

General users might only be granted access to a subset of data attributes (non-sensitive information), basic charts with restricted access to their teams, PDF export and search.





org.manager - Access granted to users that meet rules 2 and 3


External Users

As mentioned in the previous section, the access in org.manager is highly dependent on the employee record linked to each user. As such, the application requires for the users accessing it to be part of the HR data being charted.

In the event of requiring to grant access to people who are not part of the organisational hierarchy being rendered in org.manager, this can be achieved by automating the creation of artificial records for external users.



Recommendations

  • Keep the access protection rules as simple as possible. In most cases, it is possible to handle all the required access scenarios with just a few rules.

  • Avoid hard coding personnel IDs in the access protection rules as much as possible.

  • Custom fields included in the HR data imported into org.manager can be a viable solution when wanting to control the access directly from the HRIS.

  • Access protection is the most important feature to test before going live with your org.manager organisational charts. Make sure all the possible scenarios are thoroughly tested.
